Cấu Tạo Loa Bass (LF):
1 x JBL 262H - 1 300 mm / 12"
Voice Coil LF:
50.8 mm / 1.5"
Cấu Tạo Loa Treble (HF):
JBL 2408H-1 , 38 mm / 1.5"
Voice Coil HF:
38 mm / 1.5"
Trở Kháng:
8 Ohms
Tần Số Đáp Ứng:
43 Hz - 18 kHz
Độ Nhạy Max SPL:
113 dB
Cổng Kết Nối Đầu Vào (Signal Input):
NL4 Neutrik Speakon and CE- compliant covered barrier strip terminals. Barrier terminals accept accept up to 5.2 sq mm wire or max width 9 mm spade lugs. Speakon in parallel with barrier strip for loop - through
Màu Sắc:
Black
Mặt Lưới:
Powder coated , 1.5 mm perforated steel , with acoustically
Cấu Tạo Thùng Loa:
Trapezoidal with 15 degree side angles, 16 mm (5/8") exterior grade 11 - ply Finnish birch plywood
Kích Thước (WxHxD):
371 x 713 x 458 mm/ 14.6 x 28.06 x 18.1"
Cấu Tạo Loa Bass (LF):
1 x JBL 262H - 1 300 mm / 12"
Voice Coil LF:
50.8 mm / 1.5"
Cấu Tạo Loa Treble (HF):
JBL 2408H-1 , 38 mm / 1.5"
Voice Coil HF:
38 mm / 1.5"
Trở Kháng:
8 Ohms
Tần Số Đáp Ứng:
43 Hz - 18 kHz
Độ Nhạy Max SPL:
113 dB
Cổng Kết Nối Đầu Vào (Signal Input):
NL4 Neutrik Speakon and CE- compliant covered barrier strip terminals. Barrier terminals accept accept up to 5.2 sq mm wire or max width 9 mm spade lugs. Speakon in parallel with barrier strip for loop - through
Màu Sắc:
Black
Mặt Lưới:
Powder coated , 1.5 mm perforated steel , with acoustically
Cấu Tạo Thùng Loa:
Trapezoidal with 15 degree side angles, 16 mm (5/8") exterior grade 11 - ply Finnish birch plywood
Kích Thước (WxHxD):
371 x 713 x 458 mm/ 14.6 x 28.06 x 18.1"
